The Rotel DX-5 integrated stereo amplifier is a compact but powerful amplifier operating in class A/B and delivering 33 watts when operating on a load with a nominal impedance of 4 ohms (or 25 watts at 8 ohms). The new product is equipped with a power supply unit based on a powerful toroidal transformer of our own production and high-current transistors.
Connect via USB-B (32-bit/384kHz PCM, DSD 4x), coaxial/optical (24-bit/192kHz), Bluetooth aptXT HD/AAC, or the RCA analog inputs. Roon Tested certification enhances high-resolution music playback, while precision volume control (0.5dB steps, 680mV sensitivity) lets you perfect every note.
The built-in DAC based on the audiophile Sabre ES9039Q2M chip from ESS Technology provides ultra-low noise (100 dB signal-to-noise ratio) and a wide sound stage (10 Hz – 100 kHz, ±0.19 dB). Versatility is ensured by support for HDMI ARC for playing audio from TVs, an output to an active subwoofer for 2.1-channel systems and a headphone jack for personal listening.
With compact dimensions (215 x 76 x 251 mm) and a weight of 4.1 kg, the Rotel DX-5 integrated amplifier features a full-color TFT display and aluminum remote control, combining elegance and intuitiveness. The new product is offered in a black or silver design.
Rotel DX-5 Specifications
Number of Channels 2
Analog Inputs 1 (pr) x RCA
Analog Output 1 x Subwoofer
Output Power (FTC) 2 x 25 W
Frequency Response 10 Hz – 100 kHz (0 ± 0.19 dB)
Input Sensitivity / Impedance 680 mV / 100 k Ω
Digital Inputs 2 x SPDIF (coaxial, optical) LPCM (up to 24 bit / 192 kHz)
1 x HDMI-ARC
1 x PC-USB USB Audio Class 2.0 (up to 32 bit / 384 kHz) Driver Installation Required
Frequency Response 10 Hz – 80 kHz (0 ± 2 dB, max)
Input Sensitivity / Impedance -10.3 dBFS / 75 Ohm
Signal-to-Noise Ratio > 100 dB (IHF “A” weighted)
DSD/DoP DSD support (up to 4X, 11.2MHz)
Bluetooth
Wireless remote control
Power consumption 80W
Dimensions (WxHxD) 215 x 76 x 251 mm
Weight (net) 4.1 kg
